NEW 50Mega Pixel camera

S-50A30-Jx/CXP

(50M PIXEL CXP CAMERA)

출시 예정; 2017년 11월

•  50 Megapixel at 30 fps

  AMS Cmosis CMV50000 sensor

•  True Global Shutter CMOS

•  Monochrome and Color

•  PRNU and DSNU calibrated corrections

•  Configurable single, dual and quad CXP3 to CXP6 speeds

•  Hirose 12pin I/O connector

•  Adimec Connect & Grab™ support

•  Compatible to CoaXPress V1.1.1 frame grabber.

Introduction

The Sapphire 50 Mpx CoaXPress camera delivers 7920x6004 pixel resolution at over 30 fps with 4.6 micron square pixels. Camera is fully compatible with S25 and Q12 CoaXPress Adimec offers the Sapphire 50 Mpx CXP cameras in a low power, compact outline design without forced cooling through a fan. This provides an optimal design freedom for system integration with a maximum system reliability. The S-50A30 offers Connect-and-Grab™  service allowing engineers to start system development immediatly after camera installation. The camera has a stable image performance to minimize customers’ system calibration time.  Typical applications examples: - Flat panel inspection - Semiconductors metrology tools - Solar Inspection
